Product name：
Number：API SPEC 5B UPSET (E.U.E) TUBING WORKING/MASTER/TAPER GAGES
Classification：Oil Pipe Thread Gauge
API SPEC 5B UPSET (E.U.E) TUBING WORKING/MASTER/TAPER GAGES | |||||
SIZE | T.P.I | T.P.F | TAPER | ANGLE | |
1.050 EUE/UP TBG | 26.67 | 10 | 3/4 | 1:16 | 60° |
1.315 EUE/UP TBG | 33.40 | 10 | 3/4 | ||
1.660 EUE/UP TBG | 42.16 | 10 | 3/4 | ||
1.900 EUE/UP TBG | 48.26 | 10 | 3/4 | ||
2 3/8 EUE/UP TBG | 60.33 | 8 | 3/4 | ||
2 7/8 EUE/UP TBG | 73.03 | 8 | 3/4 | ||
3 1/2 EUE/UP TBG | 88.90 | 8 | 3/4 | ||
4 EUE/UP TBG | 101.60 | 8 | 3/4 | ||
4 1/2 EUE/UP TBG | 114.30 | 8 | 3/4 | ||
Instructions:
1）Implementation of standards：API SPEC 5B：2017
2）Material: GCr15， Measuring surface hardness 60-63HRC;
3）Come with the calibration certificates ,which can be tracealbe to NIM.
How to order?
For example:
Pls mark : Working Gauges:4 1/2 EU RING & PLUG, or 4 1/2 EU BOX&PIN,
and E-mail to: edwin@szfyou.com
