Thread Ring Gauges

Unified Thread Ring Gauges C Type

Date:2016/12/27 13:58:50 Hits:517

Unified Thread Ring Gauges C Type

Nominal dia  Pitch
PrimarySccondaryUNCUNFUNEF4UN6UN8UN12UN16UN20UN28UN
4    4681216
4 1/8    4681216
4 1/4    4681216
4 3/8    4681216
4 1/2    4681216
4 5/8    4681216
4 3/4    4681216
4 7/8    4681216
5    4681216
……
10    4681216

1)Implementation of standards:JB/T10865-2003,
ANSI B1.1-1982 and FED-STD-H28、H28/3(1978) Reference
2)Material: GCr15, Measuring surface hardness 53-60HRC;
3)Class:1A, 2A, 3A, 2A-0.03
How to order?
 Please specify the item size of diameter, pitch and class of the thread in your order.
For example:
Pls mark  :Unified Thread Plug Gauges: 4 3/4 -12UNC 2A GO/ NO GO 1 Sets
and E-mail to: Edwin@szfyou.com
